13 Gauge 12 Gauge 11 Gauge 10 Gauge 304 Stainless Steel Sheet For Kitchen Wall 2mm 3MM Thick

  • 13 Gauge 12 Gauge 11 Gauge 10 Gauge 304 Stainless Steel Sheet For Kitchen Wall 2mm 3MM Thick
  • 13 Gauge 12 Gauge 11 Gauge 10 Gauge 304 Stainless Steel Sheet For Kitchen Wall 2mm 3MM Thick
  • 13 Gauge 12 Gauge 11 Gauge 10 Gauge 304 Stainless Steel Sheet For Kitchen Wall 2mm 3MM Thick
  • 13 Gauge 12 Gauge 11 Gauge 10 Gauge 304 Stainless Steel Sheet For Kitchen Wall 2mm 3MM Thick
  • 13 Gauge 12 Gauge 11 Gauge 10 Gauge 304 Stainless Steel Sheet For Kitchen Wall 2mm 3MM Thick
Place of Origin Jiangsu, China
Certification ISO9001, CE
Minimum Order Quantity 1 pcs
Delivery Time 7~10working days
Payment Terms L/C, T/T
Supply Ability 5000 Ton/Tons per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Stainless Steel Sheet Type Cold Rolled,Hot Rolled
Surface No.1,2D,2B,BA,No.4,8k,Tempered Thickness 0.4mm~6mm
High Light

11 gauge stainless steel sheet metal 1200 x 600

,

12 gauge 304 stainless steel sheet 1200 x 600

,

11ga stainless steel sheet 1200 x 600
Leave a Message
Product Description

Grade 904L Stainless Steel Sheet

904L(1.4539) STAINLESS STEEL



904L is an austenitic stainless steel.In comparison to 316L, its molybdenum addition gives it superior resistance to localized attack (pitting and crevice corrosion) by chlorides and greater resistance reducing acids and in particular its copper addition gives it useful corrosion resistance to all concentrations of sulphuric acid. Its high alloying content also gives it greater resistance to chloride stress corrosion cracking, but it is still susceptible. Its low carbon content makes it resistant to sensitization by welding and which prevents intergranular corrosion.





CHEMICAL COMPOSITION

Element Cu Mn Cr Ni P S Si
904L 1.0~2.0% 2.00% 19.0~23.0% 23.0~28.0% 0.045% 0.035% 1.00%



MECHANICAL PROPERTIES

Grade

Tensile Strength

(MPa)

Min

Yield Strength

0.2% proof (MPa)

Min

Elongation

(%in 50mm)

Min

Rockwell B(HRB)
904L



490



 220 36 70~90



904L COMMON APPLICATIONS

The typical applications of grade 904L stainless steels are listed below:

  • Wiring in electrostatic precipitators.
  • Oil refinery components.
  • Seawater cooling devices.
  • Gas scrubbing plants.
  • Pulp and paper processing industries.
  • Acetic, phosphoric and sulphuric acid processing plants.
