24 Ga 26 Gauge 20 Ga 22 Gauge Galvanized Sheet Metal 4x8 4x10 AZ150 For Fencing

Place of Origin Jiangsu,China
Certification ISO 9001 ,CE
Minimum Order Quantity 1 PCS
Delivery Time 7~10 working days
Payment Terms L/C, T/T, Western Union
Supply Ability 5000 Ton/Tons per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Aluminium Zinc Alloy Coated Steel Sheet Standard ASTM,AISI,JIS,GB, DIN,EN
Type Alu-zinc Coated Width 580~1250mm
High Light

20 ga galvanized sheet metal 580 1250mm

,

24 ga galvanized sheet 580 1250mm

,

26 gauge galvanized sheet metal 580 1250mm

Leave a Message
Product Description
Hot-Dip AZ150 Aluminium Zinc Alloy Coated Steel Sheet
galvanized steel

Galvanized Steel Sheet is defined as a carbon steel sheet coated with zinc on both sides. Galvanized Steel Coil Importer produce galvanized steel with two main processes: continuous hot dip galvanizing and electro-galvanizing.



A zinc coating is one of the most effective and economical methods of protecting bare steel from a corroding environment. The zinc not only serves as a barrier between the steel and the environment, but it will also sacrifice itself to protect the underlying steel sheet. Sacrificial or galvanic protection occurs when two dissimilar metals are in contact and coupled with water and oxygen. Zinc corrodes preferentially to the iron in steel. This protection prevents corrosion of the steel at areas not covered with zinc. Thus, the spread of corrosion from cut edges, drill holes, etc. is minimized.



COATING

  Type Coating mass(g/m2) Plate thickness(mm) Width(mm)
Hot Dip Galvanized steel Hot-dip galvanealed steel sheet and coil/strips 30~120 0.5~4.5 580~1250
Hot-dip galvanized steel sheet and coil/strips 60~600 0.23~6.0 580~1250
Hot-dip zinc-aluminum-magnesium-silicon alloy coated steel sheet and coil/strips 60~275 0.27~9.0 580~1250
Hot-dip aluminum coated steel sheet and coil/strips 40~160 0.3~2.5 580~1250
Electrogalvanized steel Electrolytic zinc coated steel sheet and coil/strip 10~40 0.4~2.3 580~1250
Electrolytic zinc-nickkel coated steel sheet and coil/strip 10~40 0.4~2.3 580~1250



GRADE

DX51D+Z

DX52D+Z

DX53D+Z

S280GD+Z

S350GD+Z

S550GD+Z

DX51D+AZ

DX52D+AZ

DX53D+AZ

S280GD+AZ

S350GD+AZ

S550GD+AZ

DX51D+AZM

DX52D+AZM

DX53D+AZM

S280GD+AZM

S350GD+AZM

S550GD+AZM

SGHC

SGH400

SGCC

SGCH

SGCD

SGC400
