Plain End Din 17175 St35.8 Cold Drawn Seamless Carbon Steel Pipe Seamless Steel Tube Cs

Place of Origin Shandong China
Brand Name TESTE
Certification ISO TUV SGS BIS CE
Model Number DN50/DN80/DN100/DN150/20#
Minimum Order Quantity 3Tons
Price Negotiate
Packaging Details With iron sheet to pack the steel sheet and pallet .Also make the shipping marks on each bundles.
Delivery Time 5-15days depend on the quantity
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram,OA
Supply Ability 5000Tons Per Months

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Product Name Seamless Carbon Steel Pipe Product Name Carbon Steel Pipe
Standard DIN 17175 Grade St35.8
Type Seamless Pipe(SMLS) Thickness Schedule STD, 40, XS, 80, XXS, 160
Pipe End Plain End,Beveled End,Treaded Hight Light Plain End Din 17175 St35.8 Cold Drawn Seamless Carbon Steel Pipe Seamless Steel Tube Cs
High Light

din 17175 cold drawn seamless steel tube


st35.8 cold drawn seamless steel tube


plain end cs seamless pipe

Leave a Message
Product Description
st35.8 steel pipe NBK GBK cold drawing carbon pipes

Standard:DIN 17175 : Seamless Steel Tubes For Elevated Temperatures

As far as DIN 17175 is concerned, steels that have a good mechanical properties at a higher temperature, up to 6 00 °C, and even under long-term load, are called heat-strength steels.

DIN 17175 St35.8 Seamless Steel Tubes can be used to manufacture steam boilers, pipes, pressure vessels and instruments operating at temperatures up to 600 ° C and at high temperatures.

Plain End Din 17175 St35.8 Cold Drawn Seamless Carbon Steel Pipe Seamless Steel Tube Cs 0

Property Detail
Thickness 0.3-6mm
Length Random Length, Fixed Length
Surface Treatment Black Painting, Varnish Coating, Galvanized, 3PE, FBE
Shape Round
Processing Technique Cold Rolled/Hot Rolled/Forged
Processing Service Welding, Cutting
Useage Construction Structure
Manufacture Cold Drawn
Process Hot Dipped Galvanized Zinc Coated
Special Pipe Thick Wall Pipe
Fittings Carbon Steel Pipe Fittings
Seamless Steel Pipe Carbon Seamless Steel Pipe, High Pressure Seamless Steel Pipe, Hot Rolled Seamless Steel Pipe


Plain End Din 17175 St35.8 Cold Drawn Seamless Carbon Steel Pipe Seamless Steel Tube Cs 1



Grade C Si Mn P S Cr Mo
St35.8 ≤0.17 0.10-0.35 0.40-0.80 ≤0.040 ≤0.040 / /
St45.8 ≤0.21 0.10-0.35 0.40-1.20 ≤0.040 ≤0.040 / /
15Mo3 0.12-0.20 0.10-0.35 0.40-0.80 ≤0.035 ≤0.035 / 0.25-0.35
13CrMo44 0.10-0.18 0.10-0.35 0.40-0.70 ≤0.035 ≤0.035 0.70-1.10 0.46-0.65
10CrMo910 0.08-0.15 ≤0.50 0.40-0.70 ≤0.035 ≤0.035 0.20-0.25 0.90-1.20


Project Standard Size range Tolerance
Outer diameter DIN17175 Hot rolled steel pipe OD ≤ 100mm ± 0.75%( Min ± 0.5mm )
OD> 100~ 320mm ± 0.9%
Cold drawn steel pipe OD ≤ 120mm ± 0.6%( Min ± 0.25mm )
Wall thickness DIN17175 OD ≤ 130mm WT ≤ 2Sn +15%~-10%
WT > 2Sn~4Sn +12.5%~-10%
WT > 4Sn ± 9%
130 < OD ≤ 320mm WT ≤ 0.05OD +17.5%~-12.5%
0.05OD < WT ≤ 0.11OD ± 12.5%
WT > 0.11OD ± 10%



1. NBK(+N)
after cold forming, eventually above phase transition point, in a protective atmosphere of annealing oxidation medium
2. GBK(+A)
after cold forming, annealing in non oxidizing medium protective gas
3. BK(+C)
the final heat treatment after cold forming, therefore small steel pipe plastically, the plastically degree does not guarantee
4. BKW(+LC)
after final heat treatment, a tiny cold drawing deformation, continue again when machining steel pipe allowed inside certain limits cold deformation(bending, flaring)
5. BKS(+SR)
have a stress relief after cold forming, heat treatment, steel pipe can be carried out within a certain limit in the appropriate processing again



The 17175 St35.8 Seamless Steel Tubes Will be delivered through a suitable heat treatment. heat treatment includes:
- Normalizing
- Annealing
- Tempering; from the quenching temperature, it is not cold, but then tempered
- Adjust the mass by the isothermal transformation method.


Original material test
A thin sheet should be taken at the top end of each round or square bar ingot for a pickling test to determine if the top end is adequately cut. Ultrasonic testing can also be performed on the shrinkage hole as selected by the supplier.

- Chemical composition verification test
- hydrostatictest
- Tensile test
- Notched impact test
- Yield strength test
- Ring test
- Nondestructive testing

Plain End Din 17175 St35.8 Cold Drawn Seamless Carbon Steel Pipe Seamless Steel Tube Cs 2


Q: What is the brand name of Seamless Carbon Steel Pipe?
A: The brand name of Seamless Carbon Steel Pipe is TESTE.
Q: What are the model numbers available?
A: The model numbers available are DN50/DN80/DN100/DN150/20#.
Q: Where is Seamless Carbon Steel Pipe manufactured?
A: Seamless Carbon Steel Pipe is manufactured in Shandong, China.
Q: What certifications does Seamless Carbon Steel Pipe have?
A: Seamless Carbon Steel Pipe has ISO, TUV, SGS, BIS, and CE certifications.
Q: What is the minimum order quantity?
A: The minimum order quantity is 3Tons.
