A53 A36 Carbon Steel Plate A283 Grade C ASTM A285 Grade A B Boiler

Place of Origin Jiangsu,China
Certification ISO 9001 ,CE
Minimum Order Quantity 1 PCS
Delivery Time 7~10 working days
Payment Terms L/C, T/T, Western Union
Supply Ability 5000 Ton/Tons per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Boiler Steel Plate Delivery Conditon HR,CR,AR,Q+T,N+T,N,TMCP,UT,Z Direction
Thickness 6mm~200mm Width 2000mm/2200mm/2500mm
Length 9000mm~12000mm
High Light

a53 carbon steel plate 1.0347

,

carbon steel plate astm 1.0347

,

Carbon Steel Plate A283 Grade C 1.0347

Leave a Message
Product Description
ASTM A285 Boiler STEEL plate

The ASTM A285 specification is the Standard Specification for Pressure Vessel Plates, Carbon Steel, Low- and Intermediate-Tensile Strength intended for fusion-welded pressure vessels.



GRADE

Type Grade Standard Application
Steel plates for boilers and pressure vessels

Q245R/20g,Q345R

(S)A299M
(S)A515M(Gr.60,65,70)
(S)A204M(Gr.A,B,C)
(S)A387M(Gr.11,12,22)
(S)A537M(GL.1,CL.2)
(S)A662M(Gr.A.B,C)
(S)A302M(Gr.A,B,C,D)
(S)A737M(Gr.B,C)
(S)A738M(Gr.A,B,C)
(S)A533M(,I)
P235GH,P265GH,P295GH
P355GH,16Mo3,13CrMo4-5
...

ASTM,ASME,DIN,JIS,GB

Widely used in petroleum, chemical, power station, boiler and other industries, used to make reactors, heat exchangers, separators, spherical tanks, oil and gas tanks, liquefied gas tanks, nuclear reactor pressure shells, boiler drums, liquefied petroleum gas cylinders, Equipment and components such as high-pressure water pipes and turbine volutes of hydropower stations.



EQUIVALENT GRADE OF ASTM A285

ASTM/ASME DIN EN BS
A/SA285 Grade C DIN17155 HI EN10028 P235GH BS1501-161-Gr.360/164 Gr.360



CHEMICAL COMPOSITION-ASTM A285

Element Carbon,C Copper,Cu Iron,Fe Manganese,Mn Ohosphorous,P Silicon,Si Sulfur,S
A285 Grade A 0.17%Max - - 0.90%Max 0.035%Max - 0.035%Max
A285 Grade B 0.22%Max     0.90%Max 0.035%Max - 0.035%Max
A285 Grade C 0.28%Max - - 0.90%Max 0.035%Max - 0.035%Max



CHEMICAL COMPOSITION-ASTM A283

Element Carbon,C Copper,Cu Iron,Fe Manganese,Mn Ohosphorous,P Silicon,Si Sulfur,S
A283 Grade C 0.24%Max 0.20%Max - 0.90%Max 0.030%Max - 0.035%Max
A283 Grade D 0.27%Max 0.20%Max - 0.90%Max 0.030%Max - 0.035%Max



Where is Boiler Steel Plate Used?

  • Industrial boilers
  • Domestic hot water storage tanks
  • Compressed air storage tanks
  • Aircraft passenger cabins
  • Petrochemical storage tanks
  • Transport tanks​

Delivery status: According to the user's requirements, it can be delivered in different states such as hot rolling, normalizing, tempering, normalizing and tempering, and quenching and tempering.


Execution standard: According to the user's requirements, delivery can be made according to the following standards: national standards, metallurgical industry standards, American ASTM, ASME standards, Japanese JIS, German DIN, British BS,European EN, international ISO standards and related standards for special boards, etc.


Quality level: A, B, C, D, E and thickness direction Z15, Z25, Z35.


Flaw detection standard: according to China (JB4730, GB/T2970), the United States (A435, A577, A588), Japan (JISG0801, JISG0901), Germany (SEL072), the United Kingdom(BS5996), France (NFS04-305) and other domestic and foreign flaw detection standards production inspection.



Supplementary Technology :HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1 | S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17
